FusionServer XH321C V6

Form: 1U half-width, 2-socket, liquid-cooled server node
CPU: 1/2 × Intel® Xeon® Scalable Gen3 (6300/8300), 270W TDP
Memory: 16 DDR4 DIMMs, up to 2TB, 3200 MT/s
Storage: Up to 6× 2.5" SAS/SATA/SSD/NVMe + 2× M.2 SATA SSDs, hybrid config
RAID: 0,1,5,6,10,50,60, supercapacitor protection, M.2 RAID 0/1
PCIe/OCP: 1× PCIe x16 + 1 OCP slot
Management: BMC (Redfish, SNMP, IPMI 2.0), HTML5/VNC KVM, optional FusionDirector
OS: Windows Server, RHEL, SUSE, CentOS, XenServer, VMware ESXi
Cooling: Liquid-cooled
Operating Temp: 5°C–45°C

Chi tiết sản phẩm
Thông số kỹ thuật

Model

Form

1U half-width 2-socket liquid-cooled server node

Processors

1/2 third-generation Intel^® Xeon^® scalable processors (6300/8300 series) with 270 W TDP per processor

Memory Slots

16 DDR4 DIMM slots, up to 3200 MT/s, up to 2 TB memory capacity (configured with 128 GB memory)

Local Storage

A maximum of six 2.5-inch SAS/SATA/SSD/NVMe drives, and NVMe 2+4 balance

Up to two M.2 2280 or 2242 SATA SSDs

Hybrid configuration of different drive types

RAID

RAID 0, 1, 5, 6, 10, 50, 60, and supercapacitor power failure protection

RAID 0 and 1 for M.2 SSDs

PCIe

1 standard half-height half-length PCIe x16 slot

OCP

1 OCP expansion slot

Management

· The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.

· The BMC supports standard interfaces such as Redfish, SNMP, and IPMI2.0. Provides a remote management interface based on HTML5/VNC KVM. CD-free deployment and agentless features simplify management.

· Aggregates four compute nodes to any node management interface, simplifying management.

· FusionDirector management software is optional. It provides advanced management features, such as stateless computing, batch OS deployment, and automatic firmware upgrade, implementing intelligent and automatic management throughout the lifecycle.

Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, and VMware ESXi . For more, click here

Operating Temperature

5°C to 45°C (41°F to 113°F)

Product Certification

CE、UL、CCC、VCCI、RoHS etc

Install Package

Retractable guide rails, holding rails, and cable management racks

Dimensions (H x W x D)

40.7 mm x 218.7 mm x 632 mm (1.60 in. x 8.61 in. x 24.88 in.) (excluding the liquid-cooled water inlet and outlet pipes)
